| Housing | Powder Coated Mild Steel (MS) |
| Jars | Polycarbonate, 2 x 2 Liters Capacity |
| Overflow Protection | Mechanical Type |
| Tubing | Non-Collapsible Suction Tubing |
| Vacuum Gauge | 3.0 Inch Dial, 0–760 mmHg |
| Specification | Details |
|---|---|
| Jar Capacity | 1200 ml (Polycarbonate Jar) |
| Voltage | AC 220V, Rated Frequency 50Hz |
| Max Negative Pressure | ≥ 0.075 MPa |
| Pumping Rate | ≥ 18 L/min (High Vacuum / Low Flow) |
| Material of Jar | Polycarbonate |
| Material of Machine Body | ABS |
| Noise Level | Low Noise Operation |
| Warranty | 1 Year |
| Parameter | Specification |
|---|---|
| Power Supply | 220 Volts, 50 Hz |
| Power Consumption | 160 Watts |
| Motor Speed | 2,960 rpm |
| Suction Output | 1.5 to 15 liters/hour |
| Collection Jars | 2 × 1500 ml Glass Jars with Rubber Lids (Optional: 2 × 2000 ml Polycarbonate Jars) |
| Mobility | Mounted on 62 mm Rubber Castors |
| Optional Accessory | Foot Switch for hands-free operation |
| Specification | Details |
|---|---|
| Model | Electric Suction Machine – 1/4 HP |
| Cabinet Material | Mild Steel with Epoxy Powder Coating |
| Top Material | Stainless Steel (SS) |
| Meter & Switch | Brass |
| Jar Options | Yes, Two Options Available: (A) Polycarbonate Jars (B) Glass Jars |
| Jar Capacity | Polycarbonate: 2000 ml × 2 Jars; Glass: 1500 ml × 2 Jars |
| Jar Material | Polycarbonate jar with silicon rubber lids |
| Vacuum Range | 0 to -760 mmHg |
| Suction Control | Manual Vacuum Control Knob |
| Motor Type | Oil-Immersed Rotary Pump Electric Motor |
| Motor Speed | 2960 RPM |
| Power Consumption | 220 Volts, 50 Hz, 160 Watts |
| Gauge | Shiva brand precision gauge |
| Filter | Reusable Bacteria Filter |
| Motor Warranty | Aluminium Motor – 6 Months; Copper Motor – 1 Year (If motor is damaged due to misuse/waste entry, warranty becomes void) |
| Spare Parts Available | Jar Set, Filter, Wheels, Pipe Set |
| Wheel Material | Rubber Wheels |
| Overflow Auto Cut-Off | No – Manual machine; right jar fills first, shifts to left jar, stop manually when left jar reaches stopper |
| Handle | Tilted Handle for Easy Handling |
| Usage | Hospitals, Clinics, Nursing Homes, OT, Home-Care |
